| Specifications |
 |
 |
| Standards |
| • |
USB
2.0/1.1* |
| • |
OHCI
(Open Host Controller Interface) |
| • |
EHCI
(Enhanced Host Controller
Interface) | |
| Ports |
| • |
One
Upstream USB Type “B” Receptacle |
| • |
Seven
Downstream USB Type “A”
Receptacle | |
| Connectivity |
| • |
Up to
127 Devices by Cascading Multiple
Hubs | |
| Wiring Topology |
|
| Diagnostic LEDs |
| • |
Self-powered (Red on
self-power) |
| • |
Port
Status (Green, per
port) | |
| Temperature |
| • |
Operating: -4° to 158°F |
| • |
Storage: -40° to
158°F | |
| Humidity |
| • |
Operating: 25% ~ 95%
Non-condensing |
| • |
Non-operating: 25% ~ 95% ± 2 - 3%
Non-condensing | |
| Compliance |
|
| Dimensions |
| • |
Item
(WxDxH):4.03” x2.44” x 1.09” |
| • |
Packaging (WxDxH): 6.75” x 3.25” x
11.25” | |
| Weight |
| • |
Item:
0.19 lbs. |
| • |
Packaging: 0.9
lbs. | |
| Warranty |
|
| Minimum System
Requirements |
| • |
Computer with:
| • |
Windows Vista™***, Windows® XP
SP2, or Windows® 2000 SP4 |
| • |
Mac OS® X 10.4**** or
Higher |
| • |
USB 1.1*
Port | | |
| Package Contents |
| • |
7-Port
USB 2.0 Hub |
| • |
AC
Adapter |
| • |
USB 2.0
Cable |
| • |
Quick
Installation
Guide | |
